American Panel Corporation 8X16-O Walk In Cooler, Modular, Remote





Product Information

Walk-In Combination Freezer/Cooler, (50/50 split), 7'-6" H x 15'-5" W x 7'-9" D, Outdoor, foamed-in-place 4" urethane floor panels in freezer, floorless on vinyl screed in cooler, vinyl membrane rain roof, acrylume interior & exterior, hinged door with camlift hinges, dial thermometer, vapor proof light, 2 HP low temperature (-10° F) freezer & 3/4 HP medium temperature (35° F) cooler hermetic pre-charged remote quick-connect R448a refrigeration system, (FREEZER: condensing unit - 208v/60/1-ph, 12.6 amps; evaporator - 208v/60/1-ph, 0.9 amps fans, 4.3 amps heaters), (COOLER: condensing unit - 208v/60/1-ph, 12.7 amps; evaporator - 208v/60/1-ph, 1 amp), cover, winterization controls, refrigeration to be supplied with Heatcraft Quick Response Controller as standard

Specifications

Manufacturer American Panel Corporation
Model Number AMP-8X16-O
Packed By Each
NOMINAL SHORT SIDE 8'
NOMINAL LONG SIDE 16'
NOMINAL HEIGHT 7'-6"
INSTALLATION Outdoor

Product Dimensions

  • Height: 90.00"
  • Width: 185.00"
  • Depth: 93.00"
  • Weight: 2180.00 lbs
